By tightening the ball-ended thrust screw the workpiece is simultaneously pressed towards the stops and fixture plate. The favourable leverage enables high horizontal clamping forces. When using T-Nuts EH 23010. / EH 23020. (DIN 508) they can also be applied to other slot sizes. Material Steel, case-hardened, blackened, ground
Технические характеристики
CharacteristicsTypemechanicalApplicationsworkpieceOther characteristicseccentric, horizontal, steelClamping force
Min.: 7 kN
Max.: 21.5 kN
