The Matsuura VX-1500 is a heavy-weight vertical machining center from Matsuura and is the pioneer of vertical machining technology. The VX offers high-performance processing for components up to 2 tons in weight. The spindle offers astonishing power and accuracy.
Технические характеристики
Specifications
| Specification | Detail |
|---|---|
| X Axis Travel | 60.00 in. |
| Y Axis Travel | 27.55 in. |
| Z Axis Travel | 24.01 in. |
| Working Surface | 66.92 x 27.55 in. |
| Loading Capacity | 4,400 lb. |
| Work Surface Configuration width x number x pitch | 11/16 x 3.93 |
| Spindle Speed Range | 50 — 15,000 min-1 |
| Max Spindle Torque | 600 min-1 |
| Rapid Traverse Rate X/Y/Z | 36000 (1417.32) |
| Feedrate | 0.1 — 787.4 |
| Tool Storage Capacity | 48 |
| Max. Tool Length | 11.81 in. |
| Spindle Motor kW | AC 15/22 (low-speed winding: continuous/15min.) AC 26/30 (high-speed winding: continuous/15min.) |
