The Matsuura V.Plus-550 Vertical Machining Center acquired a full model change in 2016. The V.Plus-550 has a compact and user-friendly design. The machines highly rigid construction ensures it is ready for all applications no matter how arduous the machining environment, nor how difficult the job.
Технические характеристики
Specifications
| Specification | Detail |
|---|---|
| X Axis Travel | 21.65 in. |
| Y Axis Travel | 16.14 in. |
| Z Axis Travel | 22.04 in. |
| Working Surface | 33.85 x 15.74 in. |
| Loading Capacity | 880 lb. |
| Spindle Speed | 15,000:BT40 Standard |
| Rapid Traverse Rate X/Y/Z | 40000 min/min (1574.8 IPM) |
| Tool Storage Capacity | 30:BT40 Standard 60 or 90:BT40 Optional |
