Технические характеристики
Specifications
| Specification | Detail |
|---|---|
| X Axis Travel | 21.65 in. |
| Y Axis Travel | 17.32 in. |
| Z Axis Travel | 22.83 in. |
| Loading Capacity | 132 lb. |
| Max. Work Size | Ø,13.77 x H12.40 in. |
| Spindle Speed | 12,000:HSK-A63W Standard 15,000 or 20,000:HSK-A63W Optional |
| Rapid Traverse XYZ | 60000 m/min. |
| Rapid Traverse min-1 (B) | 50 Standard |
| Rapid Traverse min-1 (C) | 200 / 3000 (Milling Mode/Turning Mode) |
| Number of Pallets | 2 Standard 32 or 40 Tower Pallet Systems are Optional |
| Number of Tools | 60 (Chain Type) |
