With the multipoint magnetic stirrer with an integrated heating, several liquids can be simultaneously heated and mixed separately from each other. The plate of the multi position magnetic stirrer also functions as a heater. In this way, the liquids placed in the appropriate beakers can be quickly mixed as needed and simultaneously heated up to 120 degrees Celsius. The multi-position magnetic stirrer therefore offers a practical and meaningful combination of heating and / or stirring, since different media change their properties alongside with the temperature variations. A multi-position magnetic stirrer of this design mixes a wide variety of media at the same time, on several consecutively connected bases. A magnetic stirring bar, the so-called stirring flea, is immersed in a container with liquid, usually a beaker or Erlenmeyer flask, on the plate. — 5 stirring points — Adjustable up to 1500 rpm — Maximum 120°C / 248°F — Stirrable 5 x 400 ml — Timer and pulse function Drive the stirring points: Brushless motors Number of stirring points: 5 Max. Stirring quantity: 400 ml per stirring point, 2000 ml total Adjustable speed: 300 … 1500 rpm Accuracy speed: 10 RPM Heating temperature: Ambient temperature … 120°C / 248°F Accuracy temperature: ± 1°C / 1.8°F Timer range: 1 … 999 minutes — infinity Recommended length of stirring rods: 25 mm Dimensions stirring field: 456 x 118 mm / 18 x 4.6 in Heating capacity: 330 W (110 V) 375 W (220 V) Protection class: IP 42 Operating conditions: 5 … 40°C / 41 … 104°F, max. 80 rf Power supply: 110V AC / 3.6A 220V AC / 1.7A Input: 400W Dimensions: 565 x 136 x 75 mm / 22.2 x 5.4 x 3 in Weight: About 3 kg / 6.6 lbs
Технические характеристики
CharacteristicsTypemagneticDisplaydigitalProduct applicationsfor beakers, for liquidsOther characteristicshot plateRotational speed
Max.: 1,500 rpm (9,425 rad.min-1)
Min.: 300 rpm (1,885 rad.min-1)
