Clamping force blocks, pneumatic, centric clamping with spring MA CFB -MA Force maintenance in opening Self centering Force up to 41.000 N Stroke up to 16 mm Stroke control Rating IP 40 Centralized lubrication Pressurization
Технические характеристики
CharacteristicsApplicationsfor machine toolsOperationpneumaticConfigurationspringOther characteristicsself-centering, for 5-axis machining, center-clamping, concentric, double-acting, controlMax. clamping force
Min.: 6,200 N
Max.: 41,000 N
Stroke
Min.: 4 mm (0 in)
Max.: 16 mm (1 in)
