Consider the IFHA-300/150WHV for installations where diffuse, even, bright images are needed for imaging shiny objects.
The Leimac IFHA LED flat dome lights produce the diffuse illumination that is ideal for imaging reflective objects. Their design requires much less space than a traditional dome light. Furthermore, since the camera lens does not have to view the object through a small port, there are no limitations on lens type or focal length. You can even combine this light with one of our telecentric lenses.
Most models are available with white, red, blue, or NIR LEDs. Custom lights (available in quantity) can combine multiple LED colors.
(Note that the product image above may show a different size of light. Please refer to the drawing for dimensions.)
Технические характеристики
Electrical
| Power: | 30.0 W |
| Input Voltage: | 12 VDC and 24 VDC models available in most sizes |
Mechanical
| Window: | Clear |
| Window Size: | 300 x 150 mm (11.8 x 5.9) |
Environmental
| Operating Temperature: | 0 to 40C |
| Operating Humidity: | 35 — 85%, non-condensing |
Miscellaneous
| Type: | Diffuse On-Axis |
| Color: | White |
| Color Temperature: | 5000K typical |
Connectors
| Cable Length: | 0.5 m (1.6 ft) |
| Connectors: | SMR-02V-B (12V) or SMR-03V-B (24V) |
Standards
| Conformance | RoHS, China RoHS, CE IEC62471 |
