Deploy the Leimac IDBA-C7224DR red LED light for reliable, intense illumination.
The Leimac IDBA-C series feature high-density bullet-type LED elements mounted on a flat surface. They are a good, reliable source of illumination at a reasonable price. Pair with a PWM controller (sold separately) for precise intensity control.
Diffusion plates are available for when greater uniformity is needed. Polarization plates are recommended when imaging glossy objects.
Additional sizes are available in quantity. The image above is representative of general construction, but may show a different light size.
Технические характеристики
Electrical
| Drive Type: | Voltage Control |
| Power: | 5.4W |
| Input Voltage: | 12 VDC and 24 VDC models available in most sizes |
Mechanical
| Window: | Clear |
| Window Size: | 74 x 27 mm (2.9 x 1.1) |
Environmental
| Operating Temperature: | 0 to 40C |
| Operating Humidity: | 35 — 85%, non-condensing |
Miscellaneous
| Type: | Linear Array |
| Wavelength: | 660 nm typical (Red) |
Connectors
| Cable Length: | 0.5 m (1.6 ft) |
| Connector: | SMR-02V-B (12V) or SMR-03V-B (24V) |
