Description
Specifications:
- Capacity: 1000L 5 Shelf Bulk Chamber
- Voltage: 208-230V 60HZ,
- Software: Lyos Control System
- Lowest Shelf Temperature (50 Hz / 60 Hz): ≤ -67 °C / -70 °C
- Shelf Temperature Control Range: -55 to 65 °C
- Shelf Pull-Down from 20 °C to -40 °C: ≤ 30 minutes
- Lowest Condenser Temperature (50 Hz / 60 Hz): ≤ -82 °C / -85 °C
- Maximum Condenser Capacity: ≥ 35 L
- Condenser Surface Area: 750 in2 (4838 cm2)
- Condenser Pull-Down from 20 °C to -45 °C: ≤ 25 minutes
- Maximum Ice Condensing Capacity in 24 hours: ≥ 20 L
- Maximum Deposition Rate: ≥ 0.83 L/hour
- Number of Compressors: 2
- Compressor Horsepower:5 hp, 1 hp
- System Refrigerant: R508B, R407C
- Vacuum Time to 100 Millitorr: ≤ 20 minutes
- Vacuum Rate of Rise: ≤ 30 mT/hour
- Volume-Based Leak Rate: ≤ .0016 mbarꞏL/sec
- Lowest System Vacuum: ≤ 15 mT
- Temperature Uniformity: ± 1.0 °C
