The 9067-XYZ-L-M Left-Handed Stainless Steel Crossed-Roller XYZ Translation Stage is a 25.4 mm travel linear translation stage that allows you to adjust the back actuator with your left hand and adjust the side actuator with your right hand. 9067 series stages feature a generous pattern of twenty M4 and twenty one M6 threaded mounting holes. Actuators are not included. Please see specifications for recommended actuators.
Технические характеристики
- Axes of Travel X, Y, Z
- Orientation Left-Handed
- Maximum Stage Travel 25.4 mm
- Centered Normal Load Capacity 222 N
- Vertical Axial Load Capacity 80 N
- Angular Deviation 150 rad
- Material Stainless Steel
- Bearings Crossed-Roller Bearings
- Thread Type M4 and M6
- Recommended Adjustment Screw 9302
- Recommended Vernier Micrometer SM-25
- Recommended Piezo Actuator 8303
