The 9062-COM-M Low Profile Gothic-Arch Stainless-Steel Commercial Stage is a linear X translation stage with 12.7 mm travel that is designed to fit directly into your system. The stage has a 40 mm x 40 mm platform and a reduced profile by eliminating the mounting plates. M4 and M6 mounting threads.
Технические характеристики
- Axes of Travel X
- Maximum Stage Travel 12.7 mm
- Centered Normal Load Capacity 84 N
- Vertical Axial Load Capacity 26 N
- Pitch 15 arc sec
- Roll 10 arc sec
- Yaw 20 arc sec
- Material Stainless Steel
- Bearings Gothic-Arch Bearings
- Platform Size 40 x 40 mm
- Thread Type M2, M4 and M6
- Recommended Adjustment Screw 9301
- Recommended Micrometer 9355
- Recommended Piezo Actuator 8301NF
