Линейчатая дифракционная решетка, 25 x 25 мм, 250 нм, 13° Blaze, 1800 г/мм Модель: 33009FL01-061R

The 33009FL01-061R Plane Ruled Reflection Grating is 25 x 25 mm and 6 mm thick. The grating has 1800 grooves per mm a nominal wavelength at 250 nm, and a nominal blaze angle of 13°. The diffraction grating is coated with an aluminum coating on float glass substrate and designed for first order Littrow use with high efficiency in the spectral region around the blaze wavelength.

Технические характеристики

• Grating Type Plane Ruled
• Grooves per mm 1800
• Nominal Blaze Wavelength (1st Order Littrow) 250 nm
• Nominal Blaze Angle 13°

• Material Float Glass
• Size 25 x 25 mm
• Thickness 6 mm
