Certificate — EXA 15 ATEX 0070X RU C-HR.AB24.B.03246 Marking of explosion protection — II 2G EEx de IIC T2-T3 Installation — Zone 1-2-21-22 Degree of protection — IP64 Impact Resistance — IK08 Temperature — -40ºC ≤ Ta ≤ +40/50/60ºC: type II 2GD -20ºC ≤ Ta ≤ +40ºC: type I M2 Voltage — 230V AC, 110V AC, 24V AC/DC, 50Hz (60Hz on request) Material — Housing: 0403.24/10, /11, /12: aluminium powder painted casting 0403.24/20: cast iron Diffuser: borosilicate glass protected with steel grid Mounting — Directly to the surface by hooks Inputs — 2 x M25 (1 plugged) Lamps — Incandescent lamps, E27 lampholder, up to 100W Halogen lamps, E27 lampholder, 77W A ECO
Технические характеристики
CharacteristicsTypelight fittingIllumination technologyincandescent, halogenProtection levelIP64Other characteristicssurface, ATEX, borosilicate glassPower
Max.: 400 W
Min.: 60 W
