Description
Leica DM2700P for research and development
the Leica DM2700 P offers a level of reproducibility that is one-of-a-kind in its class, the built-in focus stop protects your samples and the front lens of the objective. For samples of equal height, the focus stop makes the focusing plane easier to reconstruct so you can concentrate entirely on your application. Color-coded lenses match the color-coded field and aperture diaphragm adjustment (CDA), to ensure that the illumination conditions are always matched to the objective. Constant color temperature by advanced LED technology
› Build-in incident light oblique illumination
› Height-adjustable focus knobs
› Color-coded objectives and condenser diaphragms match lenses
› Integrated focus stop prevents objective/sample collisions
- Objective turret: 5x (M25), centerable
- Objectives: HiPlan POL, NPlan POL, PL Fluotar POL, Inmersion Objectives
- Contrast method Changeover: Manual
- Transmitted light: Orthoscopy, Colonoscopy, Brightfield, Phase contrast, DIC, Darkfield
- Incident light: Brightfield, DIC, Fluorescence Oblique illumination
- Colonoscopy: Bertrand lens cube Bertrand lens module (AB module) Advanced colonoscopy module (manual)
- Transmitted light axis Illumination operation: High power LED Manual, User guidance with CDA
- Incident light axis: Manual, High power LED User guidance with CDA
- Condenser: Manual changeover User guidance with CDA
- Focus drive: Manual, height-adjustable, Focus stop, 2 or 3-gear gearbox Motorization on request
