Blue line Industrial Panel PC Industrial high performance panel PC with full size PCI and PCIe expansion slots to support e.g. Video frame grabber and multiple LAN / USB ports. Perfect for AI and Machine Vision. Available with stainless steel front for support of extensive cleaning. • Full size PCI and PCIe expansion slots • Front Bezel IP66 • Available with stainless steel front • 15′ to 21.5′ PCAP multi touch display • Integrated PC • ThinManager support • Intel i3 / i5 / i7 / Celeron • Windows 7 / 8 /10 • Broad range of input/output • Customisation according to your requirements Model Type HMI stainless steel Panel PC Construction Front bezel in aluminium or stainless steel AISI 304 or 316L Cooling Fanless with Celeron N2930 CPU Active fan with Core i3 / i5 / i7 Ingress Protection Front IP66 (option for front IP69K) Environment Operating temperature — 0°C to +50°C Storage temperature — -30°C to +70°C Humidity — 10 to 95% @ 40°C, (non- condensing) Certification CE / FCC Class A
Технические характеристики
CharacteristicsScreen typeLCD, touch screenDisplay size15, 21.5, 17Resolution1024 x 768, 1920 x 1080, 1280 x 1024, 1366 x 768ProcessorIntel® Celeron N2930, Intel® Core i5, Intel® Core i3, Intel® Core i7, 6th generation Intel® Core™, 7th Generation Intel® Core™ i7ApplicationsindustrialOther characteristicsfanless, HMI, stainless steel, Windows 7, IP66, IP69K
