Технические характеристики
| Dynode Stages | 26 |
|---|---|
| Dynode Structure | Linear focused |
| Dynode Material | Al2O3 |
| Input Aperture Diameter | 11 dia. mm |
| Rise Time Typ. | 7 ns |
| Anode to All Other Electrode Capacitance | 3 pF |
| Supply Voltage(Analog Part) | -1800 V |
| Supply Voltage(Counting Part) | 1000 V |
| Supply Voltage(Gate) | 230 V |
| Gain Typ.(Analog Part) | 2.0 x 104 |
| Gain Typ.(Counting Part) | 3.0 x 107 |
| [Max. Rating] Supply Voltage(Analog Part) | -3000 V |
| [Max. Rating] Supply Voltage(Coiunting Part) | 2500 V |
| [Max. Rating] Operationg Gain | 1.0 x 108 |
| [Max. Rating] Average Anode Current | 10 μA |
| [Max. Rating] Operating Vacuum Level | 0.01 Pa |
