Separating substances at medium rotational speeds: IKA G-L is the ideal midi centrifuge for all types of separation processes such as those found in molecular biology. It can be used with standard 1.5/2 ml vessels, as well as with PCR strips. The cover opens automatically at the press of a button. Safe use The centrifuge is fitted with a metal cover and does not start until it is firmly closed. State-of-the-art display The completely intuitive navigation is carried out through a membrane keypad. This allows an easy setting of speed, rotational speed or programmes. Powerful motor With a rotational speed of up to 15,700 rpm, the centrifuge is fitted with a high-performance motor. Broad scope of delivery Metal rotor and cover for 12 vessels, with a capacity of 1.5/2 ml, are already included in the scope of delivery. Technical Data Capacity : 12 x 1.5/2.0 ml Pemitted density : 1.2 kg/dm3 Centrifugal acceleration : 16500 G Motor rating input : 65 W Speed range : 800 — 15700 rpm Speed deviation : 2.5 % Setting accuracy speed : 100 ±rpm Timer : yes Timer display : 7 segment LED Unbalance sensor : yes Quick stop : yes Cover opening : automatic Rotor exchange : without tool Protective cover : yes Dimensions (W x H x D) : 200 x 140 x 280 mm Weight : 3.9 kg Permissible ambient temperature : +5 — +40 °C Permissible relative humidity : 80 % Protection class according to DIN EN 60529 : IP 20 USB interface : yes Voltage : 220 — 230 / 115 / 100 V Frequency : 50/60 Hz Power input : 92 W Power input standby : 18 W
Технические характеристики
CharacteristicsApplicationslaboratoryOrientationverticalOther characteristicstop-loadingRotational speed
Max.: 15,700 rpm (98,646 rad.min-1)
