The 9873-K Tiny Blank Plate Mount is our most compact platform mount for applications where space is truly tight. Designed with the same mechanical principles as our larger classic mounts, it offers over 2 mm of pure translation, ±,4 of tilt, and a 2-56 threaded hole for platform mounted optics. It has 6-80 adjustment screws and #2 (M2) clearance holes for mounting. All our Tiny mounts come standard without knobs. If you need knobs to adjust these mounts in your experiment, you can order our model 9365 Tiny knobs. Optics can directly be glued on the platform or you can use an optic holder compatible with the threaded hole in the platforms center if removal of optics from the platform mount is needed.
Технические характеристики
- Mechanism Kinematic
- Platform Size 23.1 x 23.1 mm
- Number of Actuators 3
- Actuator Locks No
- Adjustment Screw Thread 80 TPI
- Adjustments z, x, y
- Sensitivity 14.3 arc sec
- Angular Range ±4°
- Material Stainless Steel
- Drive Type Allen-Key, non-locking
- Platform Thread 2-56 THD
- Mounting Holes 2-56 (M2) CLR
