The LDM-4984T is designed for typical 14-pin telecommunication butterfly laser diode packages and includes a separate case temperature control for applications requiring tight temperature stability. Zero insertion force (ZIF) sockets and spring-loaded clamps facilitate ease of mounting. The LDM-4984T features the ILX Lightwave standard 9-pin D-sub input connectors with configurable pin designations to accommodate virtually any laser diode pin configuration.
Технические характеристики
- Package Type 14-pin Butterfly
- Laser Current 2 A
- TE Cooler Yes
- TE Current Range -6.0 to +6.0 A
- TE Voltage Range -4.2 to +4.2 V
- Temperature Range -5 to 85°C
- Temperature Sensor 10 k NTC Thermistor
- Laser Driver Connector Type Female 9-pin DSUB
- TEC Controller Connector Type Male 9-pin DSUB (TEC) / 9-pin DSUB (Case TEC)
- Dimensions 39.4 x 140 x 140 mm
