Product Description GMI is the trusted scratch & dent factory outlet partner of NuAire. This item has minor cosmetic damages (pictures available upon request), but its performance is backed by a full manufacturers warranty. #text-2898262577 { line-height: 1.25, } Standard Features AeroMax Electronic Control System Ultra-high Efficiency DC/ECM Motor PressureFlow Airflow Monitor and Control Attenumount Vibration Control HEPEX Zero Leak Airflow System True Laminar Airflow Pre-Filter System Metal Frame Supply Separatorless HEPA Filter 99.99% efficient @ 0.3 micron ISO Class 5 Air Backwall Metal Diffuser with Quick Clean Removal Cool White Fluorescent Lighting Stainless Steel Sidewalls with Cord Pass-Through Stainless Steel Worksurface with PVC Core Ergonomically Designed Work Zone Power Cord #image_763906074 { width: 53%, } GREEN LIGHT, YELLOW LIGHT, RED LIGHT AEROMAX CONTROL SYSTEM The Aeromax control system visualizes airflow plenum pressure through a series of multicolored lights and activates both an audible and visual alarm whenever workbench performance departs from normal parameters. #image_661093616 { width: 56%, } SMOOTH SURFACES & CONFIGURATIONS FOR A SMOOTH WORKFLOW STAINLESS STEEL WORK ZONE The stainless-steel sidewalls and stainless-steel work surface with PVC core provide a work zone that is robust, cleanable. Two standard cord-pass throughs and an optional outlet under the work surface or IV bar with 6 hooks make it an ideal primary engineering control for your pharmacy or clean air workbench for your microbiology laboratory. Technical Specifications Model Specification NU-340-330 NU-340-336 Nominal 3 foot (0.9m) NU-340-430 NU-340-436 Nominal 4 foot (1.2m) NU-340-530 NU-340-536 Nominal 5 foot (1.5m) NU-340-630 Nominal 6 foot (1.8m) Performance Specifications 1. Product Protection IEST-RP-CC002.4 ISO 14644-1 IEST-RP-CC002.4 ISO 14644-1 IEST-RP-CC002.4 ISO 14644-1 IEST-RP-CC002.4 ISO 14644-1 ISO 14644-1 ISO 5 ISO 5 ISO 5 ISO 5 Style of Work station Console Console Console Console Work station Construction 16/18 GA, powder coated steel exterior, 16/18 GA type 304 SST work zone 16/18 GA, powder coated steel exterior, 16/18 GA type 304 SST work zone 16/18 GA, powder coated steel exterior, 16/18 GA type 304 SST work zone 16/18 GA, powder coated steel exterior, 16/18 GA type 304 SST work zone Diffuser for Air Supply (Metal) Non-flammable Non-flammable Non-flammable Non-flammable HEPA Filter Seal Type: Supply Filter-99.99% Eff. on 0.3 microns HEPEX Seal- Neoprene, Spring-loaded HEPEX Seal- Neoprene, Spring-loaded HEPEX Seal- Neoprene, Spring-loaded HEPEX Seal- Neoprene, Spring-loaded Optional Services Service Coupling (3/8 inch NPT) (3) Right/left sidewalls (3) Right/left sidewalls (3) Right/left sidewalls (3) Right/left sidewalls Gas Valve/Service Coupling (3/8inch NPT) (3) Right/left sidewalls (3) Right/left sidewalls (3) Right/left sidewalls (3) Right/left sidewalls Outlet (2) Right/left sidewalls (2) Right/left sidewalls (2) Right/left sidewalls (2) Right/left sidewalls Work station Size Inches (mm) Height (w/30 HEPA filter) 75 3/4 (1924) 75 3/4 (1924) 75 3/4 (1924) 75 3/4 (1924) Height (w/36 HEPA filter) 81 3/4 (2076) 81 3/4 (2076) 81 3/4 (2076) 81 3/4 (2076) Width 38 (965) 50 (1270) 62 (1575) 74 (1880) Depth 32 (813) 32 (813) 32 (813) 32 (813) Work Zone Inches (mm) Height (w/30 HEPA filter) 32 (813) 32 (813) 32 (813) 32 (813) Height (w/36 HEPA filter) 38 (965) 38 (965) 38 (965) — Width 35 7/8 (911) 47 7/8 (1216) 59 7/8 (1521) 71 7/8 (1826) Depth 19 5/8 (498) 19 5/8 (498) 19 5/8 (498) 19 5/8 (498) Airflow Volume at 90 fpm (.46 mps) CFM/CMH 30 HEPA filter 718 (1220) 958 (1628) 1198 (2036) 1438 (2443) 36 HEPA filter 852 (1448) 1137 (1932) 1422 (2416) 1707 (2900) Heat Rejected, BTU, Per Hour 30 HEPA filter 863 1256 1648 1962 36 HEPA filter 1099 1491 1884 2119 Work station weights*** Crated Shipping Weight (30) 370 lbs. /168 kg. 440 lbs. /200 kg. 510 lbs. /231 kg. 610 lbs. /277kg. Net Weight (30) 330 lbs. /150 kg. 390 lbs. /177 kg. 460 lbs. /209 kg. 540 lbs. /245 kg. Crated Shipping Weight (36) 385 lbs. /175 kg. 455 lbs. /252 kg. 530 lbs. /240 kg. 630 lbs. /286 kg. Net Weight (36) 345 lbs. /156 kg. 405 lbs. /184 kg. 480 lbs. /218 kg. 560 lbs. /254 kg.
Технические характеристики
Technical Specifications
Model | ||||
| Specification | NU-340-330 NU-340-336 Nominal 3 foot (0.9m) | NU-340-430 NU-340-436 Nominal 4 foot (1.2m) | NU-340-530 NU-340-536 Nominal 5 foot (1.5m) | NU-340-630 Nominal 6 foot (1.8m) |
| Performance Specifications 1. Product Protection | IEST-RP-CC002.4 ISO 14644-1 | IEST-RP-CC002.4 ISO 14644-1 | IEST-RP-CC002.4 ISO 14644-1 | IEST-RP-CC002.4 ISO 14644-1 |
| ISO 14644-1 | ISO 5 | ISO 5 | ISO 5 | ISO 5 |
| Style of Work station | Console | Console | Console | Console |
| Work station Construction | 16/18 GA, powder coated steel exterior, 16/18 GA type 304 SST work zone | 16/18 GA, powder coated steel exterior, 16/18 GA type 304 SST work zone | 16/18 GA, powder coated steel exterior, 16/18 GA type 304 SST work zone | 16/18 GA, powder coated steel exterior, 16/18 GA type 304 SST work zone |
| Diffuser for Air Supply (Metal) | Non-flammable | Non-flammable | Non-flammable | Non-flammable |
| HEPA Filter Seal Type: Supply Filter-99.99% Eff. on 0.3 microns | HEPEX Seal- Neoprene, Spring-loaded | HEPEX Seal- Neoprene, Spring-loaded | HEPEX Seal- Neoprene, Spring-loaded | HEPEX Seal- Neoprene, Spring-loaded |
| Optional Services | ||||
| Service Coupling (3/8 inch NPT) | (3) Right/left sidewalls | (3) Right/left sidewalls | (3) Right/left sidewalls | (3) Right/left sidewalls |
| Gas Valve/Service Coupling (3/8inch NPT) | (3) Right/left sidewalls | (3) Right/left sidewalls | (3) Right/left sidewalls | (3) Right/left sidewalls |
| Outlet | (2) Right/left sidewalls | (2) Right/left sidewalls | (2) Right/left sidewalls | (2) Right/left sidewalls |
| Work station Size Inches (mm) | ||||
| Height (w/30” HEPA filter) | 75 3/4 (1924) | 75 3/4 (1924) | 75 3/4 (1924) | 75 3/4 (1924) |
| Height (w/36” HEPA filter) | 81 3/4 (2076) | 81 3/4 (2076) | 81 3/4 (2076) | 81 3/4 (2076) |
| Width | 38 (965) | 50 (1270) | 62 (1575) | 74 (1880) |
| Depth | 32 (813) | 32 (813) | 32 (813) | 32 (813) |
| Work Zone Inches (mm) | ||||
| Height (w/30” HEPA filter) | 32 (813) | 32 (813) | 32 (813) | 32 (813) |
| Height (w/36” HEPA filter) | 38 (965) | 38 (965) | 38 (965) | ———- |
| Width | 35 7/8 (911) | 47 7/8 (1216) | 59 7/8 (1521) | 71 7/8 (1826) |
| Depth | 19 5/8 (498) | 19 5/8 (498) | 19 5/8 (498) | 19 5/8 (498) |
| Airflow Volume at 90 fpm (.46 mps) CFM/CMH | ||||
| 30” HEPA filter | 718 (1220) | 958 (1628) | 1198 (2036) | 1438 (2443) |
| 36” HEPA filter | 852 (1448) | 1137 (1932) | 1422 (2416) | 1707 (2900) |
| Heat Rejected, BTU, Per Hour | ||||
| 30” HEPA filter | 863 | 1256 | 1648 | 1962 |
| 36” HEPA filter | 1099 | 1491 | 1884 | 2119 |
| Work station weights*** | ||||
| Crated Shipping Weight (30”) | 370 lbs. /168 kg. | 440 lbs. /200 kg. | 510 lbs. /231 kg. | 610 lbs. /277kg. |
| Net Weight (30”) | 330 lbs. /150 kg. | 390 lbs. /177 kg. | 460 lbs. /209 kg. | 540 lbs. /245 kg. |
| Crated Shipping Weight (36”) | 385 lbs. /175 kg. | 455 lbs. /252 kg. | 530 lbs. /240 kg. | 630 lbs. /286 kg. |
| Net Weight (36”) | 345 lbs. /156 kg. | 405 lbs. /184 kg. | 480 lbs. /218 kg. | 560 lbs. /254 kg. |
