The SL-600-422TC LabLegs Vibration Isolator Set offers vibration isolation at a very affordable price, with flanges for optional tie-bar or tie-bar castor system (TB series tie-bar or TBC series tie-bar castor system purchased separately). The set includes (4) 22 inch isolators with a 2400 lb total load capacity and flanges for optional tie-bar/tie-bar castor system. The isolators remove floor vibrations in the 10 Hz to 50 Hz range and support a wide variety of less rigorous research and production applications.
Технические характеристики
- Isolator Height 22 in. (558.8 mm)
- Load Capacity per Isolator 600 lb (272 kg)
- Number of Isolators 4
- Tie Bar Flange Yes
- Horizontal Isolation, Resonance 1.5 Hz
- Horizontal Amplification at Resonance 13 dB
- Horizontal Isolation, 10 Hz 98%
- Vertical Isolation, Resonance 3.5 Hz
- Vertical Amplification at Resonance 9 dB
- Vertical Isolation, 10 Hz 94%
- Maximum Air Pressure 80 psi (551 kPa)
- Crated Weight 261 lb
