last updated : 2020/03/21
| Code | Description | Budget Price | Ship. weight | Ship. vol. | ||
|---|---|---|---|---|---|---|
| KRELSHEK05 | SHELTER KIT, SAHEL, tarpaulins, frame and fixings | on request | 0kg | 0 | Add | |
General information
The Sahel Shelter Kit is designed as a context base emergency shelter solution suitable for the Sahel region of Western Africa.
Assessment with National Societies from this region has confirmed that this Sahel shelter kit performed in the Sahel context.
The Sahel Shelter Kit matches the following requirements:
Requirement | Value |
Shelter covered surface | Minimum 20m2 |
Approx. price per unit in the local market | 250CHF |
Construction time | 6 h to 1 day (with 4 to 6 persons) |
Target durability of the shelter in predefined conditions | Minimum 12 months |
Items from warehouse stocks | 100% of the items |
Target warehouse time | 3 years |
Perimeter protection: The proposed solution is a barrier with sand bags positioned around the perimeter of the shelter. The bags are made from plastic sacks available in the local market. They are cut in half and sewn by hand to form tubes and finally filled with sand (or available soil) from the site. The plastic bags have to be placed inside the shelter to protect the plastic from the UV radiation and hold down the shade net walls.
The kit is designed for family distribution (base on 5 persons / family), one kit per family.
This kit includes tools and materials including framing and cover.
Specifications
Refer to individual Product Specification Sheets (click on items in the content list below).
KRELSHEK05 Content list — Export content list (excel file)
| Code | Description | Qty |
|---|---|---|
| APACBAGPR09 | BAG, PE plastic, for rubble, 300x400x900mm | 16 |
| EBUIPOSTST13 | POST, square steel pipe 1.6mm,30x30mmx1.3m | 4 |
| EBUIPOSTST14 | POST, square steel pipe 1.6mm,30x30mmx2.1m | 6 |
| EBUIPOSTST15 | POST, square steel pipe 1.6mm,30x30mmx2.5m | 2 |
| EHDWWIRETR151 | TIE WIRE, galvanised, diam. 1.5 mm, 100m, roll | 2 |
| EMEATAPMRO52 | MEASURING TAPE, 5m, 19mm tape, metric and inch, rolling case | 1 |
| ETOONEELC12 | NEEDLE, stitching, curved, 127mm x 1.8mm, hole 1x7mm | 1 |
| ETOOPLIC2024 | PLIER, nippers, up to 2mm hard wire, 240mm length | 1 |
| ETOOSAWSW400 | HANDSAW, for timber, 400mm blade | 1 |
| HSHEMATTPLA6 | MAT, plastic 120 x 220 cm | 16 |
| HSHEROPE01N | ROPE, NYLON, polyamide, d:1mm,braided string, per m | 100 |
| HSHEROPE05P | ROPE, POLYPROPYLENE, diam. 5mm, twisted, per m | 100 |
| HSHESHADNP801 | SHADE NETTING, w:4m, black PP fibers, 80% shade, per m | 16 |
| HSHETARPW406 | TARPAULINS, woven plastic, 4 x 6 m, white/white, piece | 2 |
| WNEHPVRI5 | HOSE, PVC, RIGID, out.d. 32mm,NP10, L=6m | 24 |
