The LDC-3916374 Combination Laser Diode Controller Module offers both a 1000 mA laser diode driver, and a 9 W TEC controller in the same module.
Технические характеристики
- Type LDC-3908/3916 Controller Card
- Laser Current 1 A
- Laser Compliance Voltage 6 V
- TE Current Range -1.50 to +1.50 A
- TE Voltage Range -7.00 to +7.00 V
- TE Output Power 9 W
- Temperature Range –99.9 to 199.9°C
- Laser Current Resolution 0.02 mA
- Laser Current Accuracy ±0.1% of FS
- Current Output 24 h Stability 50 ppm FS
- Current Output 1 h Stability 20 ppm FS
- External Modulation High Bandwidth 1 MHz
- External Modulation Low Bandwidth 30 kHz
- Laser Output Noise/Ripple Low Bandwidth 5 A
- Laser Output Noise/Ripple High Bandwidth 10 A
- Forward Voltage Accuracy ±7mV
- Forward Voltage Resolution 10 mV
- TEC Current 24h Stability
- TEC Current 1h Stability
- TEC Ripple/Noise (rms)
- Photodiode Current Range 0 — 5000 A
- Photodiode Current Resolution 0.1 A
