Description
The Kobold BGN Series variable area flow Meters are ideal for difficult applications that require high pressure capability, high temperature operation, or low pressure loss. The BGN’s standard design is available in stainless steel, PTFE-clad stainless steel, or Hastelloy C-22. The standard BGN is well suited for water, most viscous liquids, and compressed gases in line sizes up to 6′. The direct reading scales are calibrated for media viscosity, density, operating pressure, and temperature. Electronic limit switches and an analog flow transmitter are available as options and are able to operate via intrinsically safe methods of protection and may be used in hazardous areas where intrinsically safe installations are permitted. Custom designs for high pressure, high temperature, special fittings, and special materials (such as Monel and tantalum) are available. Other options include: self-draining flow bodies, gas or liquid damping, and a flow counter module.
Технические характеристики
Features
- Measuring ranges:
- Water, (0.0022 to 0.022) up to (57.24 to 572.2) GPM
- Air, (0.008 to 0.08) up to (64.74 to 647.4) SCFM
- Accuracy liquid:
- ±1.6% of Full Scale (BGN-S/H)
- ±2.0% of Full Scale (BGN-P)
- Accuracy gas:
- ±1.8% of Full Scale (BGN-S/H)
- ±2.2% of Full Scale (BGN-P)
- Connection:
- 1/2′ to 6′ ANSI
- 1/4′ to 2′ NPT
- Materials: SST, Hastelloy C-22, PTFE
- A large spectrum of wetted materials
- Magneto-resistive signal transmission
- Gas- or liquid damping (option)
- Excellent heat tracing technology (option)
A completed BGN application data form is required for a new meter. For a replacement, your serial number will suffice.
