Description
Andor»s iXon3 860 back-illuminated EMCCD is designed for very rapid imaging of low light events. The iXon3 860 benefits from an advanced set of user–requested features, including OptAcquire, Count Convert, Spurious Noise Filters & Signal Averaging. RealGain provides quantitative EM gain calibration. Sub-millisecond biology is readily accessible through use of sub-array selection, pixel binning and Cropped Sensor Mode pushes frame rates to new extremes. The speed and sensitivity of the iXon3 860 also renders it ideal for adaptive optics.
Specifications:
- Active Pixels: 128 x 128
- Pixel Size: 24 x 24 um
- Active Area Pixel Well Depth: 160,000 e-
- Gain Register Pixel Well Depth: 800,000 e-
- Maximum Readout Rate: 10 MHz
- Frame Rate: 513 – 14,025 fps
- Read Noise: <, 1e- with EM gain
- Maximum Cooling: -100°C
