Basic Series ( COUPLINGS WITH HUBS ) to assemble with bore and keyway. With the same spider size, different coupling models can be interchanged, as well as with other coupling SERIES.
Технические характеристики
CharacteristicsTypejawInstallation systemflangeTorque
Max.: 1,500 Nm (1,106.3432 ft.lb)
Min.: 1.1 Nm (0.8113 ft.lb)
Rotational speed
Max.: 10,000 rpm (62,831.85 rad.min-1)
Min.: 1,750 rpm (10,995.57 rad.min-1)
