The 66926-1000HXF-R07 High Power Mercury-Xenon Light Source is a complete, plug and play light source suitable for applications where intense UV-NIR output is required. The light source includes an 1000 W Ozone Free Hg-Xe arc lamp, Hg-Xe lamp socket adapter, research series lamp housing, interconnection cables and the lamp power supply. After a quick and easy assembly, the light source is ready for use and can be easily integrated into a users setup.
Технические характеристики
- Type Mercury-Xenon Light Source
- Lamp Type Hg(Xe), Ozone Free
- Lamp Wattage 1000 W
- Output Beam Size 69 mm
- Condenser Type Four Element Aspherab
- F/# F/0.7
- Output Beam Collimated
- Lens Material Fused Silica
- Lens Transmittance Range 200 — 2500 nm
- Lens Multiplication Factor 0.2
- Light Ripple
- Power Requirements 95 — 264 VAC
- Flange Series Size 3 Inch
- Horizontal Intensity 5000 cd
