The SWAN 085 vacuum is the ideal industrial vacuum cleaner for the pharmaceutical industry. It can be used for technical cleaning or it can be connected on machines for continuous service, including 24/7 use. SUCTION UNIT The suction unit is a side channel blower with direct coupling between motor and impeller. The side channel blower is equipped with a safety valve to guarantee continued work in complete safety, without any maintenance. The blower is also equipped with a metal silencer to maintain a low noise level. FILTERING ELEMENT The filtration is guaranteed by an M class polyester filter. The star shape enables air to flow through the filter even when it is dirty. The fabric of the filter is classified as M Class (BIA | EN 60335-2-69). This means that all particles till 1 micron are stopped by the filter so as to protect the blower and the operator around the vacuum cleaner. SUCTION INLET The tangential inlet is designed to ease the process of pushing the material down the bin. A sturdy metal cyclone welded inside the chamber slows the material’s entry speed considerably down so that it falls directly inside the bin. This way, the filter is efficiently protected, minimizing clogging risk. COLLECTION BIN The material is collected inside a painted container. Through the lever installed on the front part of the machine it is possible to operate the mechanism that keeps the container in working position. Once lowered, the container can then be easily extracted to empty it thanks to the two ergonomic handles
Технические характеристики
CharacteristicsDomainindustrialType dryPower sourcethree-phaseContainer typesteelConfigurationmobileApplicationsfor the pharmaceutical industryOther characteristicscompactPower
850 W
Capacity
35 l (9.2 gal)
Air flow
150 m³/h (5,297.2 ft³/h)
Vacuum
210 mbar (3 psi)
Noise level
64 dB
Weight
75 kg (165.35 lb)
Height
1,600 mm (63 in)
Length
750 mm (29.5 in)
Width
500 mm (19.7 in)
