The PUMA 25 is a heavy-duty industrial vacuum for working in harsh conditions with heavy materials. It can be used for a small centralised system to supply multiple suction points. SUCTION UNIT The suction unit is a side channel blower with direct coupling between motor and impeller. The side channel blower is equipped with a safety valve to guarantee continued work in complete safety, without any maintenance. The blower is also equipped with a metal silencer to maintain a low noise level. FILTERING ELEMENT The filtration is guaranteed by an M class polyester filter. The star shape enables air to flow through the filter even when it is dirty. The fabric of the filter is classified as M Class (BIA | EN 60335-2-69). This means that all particles till 1 micron are stopped by the filter so as to protect the blower and the operator around the vacuum cleaner. INLET The tangential inlet is designed to ease the process of pushing the material down the bin. A sturdy metal cyclone welded inside the chamber slows the material’s entry speed considerably down so that it falls directly inside the bin. This way, the filter is efficiently protected, minimising clogging risk. COLLECTION BIN The material is collected inside a painted container equipped with a metal handle which enables the bin to be detached from the machine. Thanks to its 4 swiveling wheels, the bin can be easily moved and emptied. Each wheel is reinforced to guarantee maximum stability during handling.
Технические характеристики
CharacteristicsDomainindustrialSubstance vacuumedwet and dryPower sourcethree-phaseContainer typesteelConfigurationwheel-mountedApplicationsfor hazardous environmentsPower
18.5 kW
Capacity
175 l (46.2 gal)
Air flow
1,380 m³/h (48,734.2 ft³/h)
Vacuum
440 mbar (6 psi)
Noise level
74 dB
Weight
370 kg (815.71 lb)
Height
1,980 mm (78 in)
Length
1,550 mm (61 in)
Width
850 mm (33.5 in)
