DUST CONTAINMENT SYSTEM FOR HPAPI OEB4 — OEB5 INGREDIENTS The Pharma 40DC industrial vacuum cleaner is a compact, quiet and flexible unit designed for dust containment during operations with highly powerful HPAPI active ingredients. The construction, designed to provide maximum dust filtration and total operator safety, fully complies with GMP guidelines. All maintenance operations are carried out by using systems that guarantee maximum safety, making it suitable for work with pharmaceutical powders and guaranteeing filtration levels up to OEB4 / OEB5. The polished AISI316 stainless steel cyclone separates 98% (maximum, tested with placebo dust) of the extracted dust without the use of a filter unit and with no maintenance required. The Wash in place optional is available for the internal cleaning of the unit. The remaining dust is retained by a HEPA absolute filter that can filter dust up to 0.18 microns with an efficiency of 99.995% (with the possibility of installing 2 more, one on the intake and one on the air outlet) and a Bibo (BagIn-BagOut) system, which allows the absolute filter to be replaced without coming into contact with the sucked-in dust. All parts in contact with pharmaceutical powders are made of AISI316 stainless steel, which is perfect for material flow and simplifies cleaning operations of the unit. The frame is made of AISI304 stainless steel. The Atex Z22 certified version of the unit is available on request.
Технические характеристики
CharacteristicsDomainindustrialSubstance vacuumedhazardous dustPower sourceelectricContainer typestainless steelConfigurationwheel-mountedOther characteristicscompactPower
4 kW
Capacity
30 l (7.9 gal)
Air flow
420 m³/h (14,832.2 ft³/h)
Vacuum
254 mbar, 313 mbar (4 psi)
Noise level
69 dB
Weight
160 kg (352.74 lb)
Height
232 cm (91.3 in)
Length
95 cm (37.4 in)
Width
56 cm (22 in)
