OIL & SWARF The CLEAN AIR 800 separator is extremely compact with reduced dimensions because the electric ventilator is installed internally. The filter unit has been made to purify the air in working environments and recover the oil, allowing recycling. Filtration is guaranteed by a special cartridge with high filtering surface (IFA-BGIA certified, Class M, 98% efficiency, Directive DIN 60335-2). BACKWARD BLADES IMPELLER The backward curved impeller blades, specifically designed to generate a powerful coalescent effect, are primarily conceived to avoid, along all the machine’s life, any phenomenon of imbalance and the subsequent vibrations. The impeller silently conveys the air flow towards the interior of the machine. LABYRINTH PRE-FILTER After going through the impeller, the fluids go through an efficient labyrinth pre-filter. Thanks to the particular angle at which it is settled, it increases the impact area of the intake air by 20% and its subsequent separating performance. At this stage the most of the oily mist has already been removed. CELLULOSE FILTER CARTRIDGE After the labyrinth pre-filter, there is a special cartridge with high filtering surface (IFA-BGIA certificate, classification M, efficiency 98%, directive DIN EN 60335-2), surrounded by a washable coalescent mat which can be regenerated via washing. The two components are able to capture the remaining micro-mist which may have accumulated inside the cartridge thus guaranteeing longer maintenance intervals and less filter replacements OIL DRAIN SYSTEM The dual drainage system of the condensed coolant, provides perfect and efficient drainage in any application.
Технические характеристики
CharacteristicsDomainindustrialSubstance vacuumedoil and chipPower sourceelectricConfigurationstationaryApplicationsfor the metallurgical industryOther characteristicscompact, with solid-liquid separatorPower
370 W (1,262.5 BTU/h)
Air flow
800 m³/h (28,251.7 ft³/h)
Noise level
66 dB
Weight
40 kg (88.18 lb)
Height
550 mm (21.7 in)
Length
570 mm (22.4 in)
Width
550 mm (21.7 in)
