The radial piston pump type R consists of valve-controlled pump elements arranged in star form around an eccentric. For large flow rates, up to 42 pump elements can be set up in 6 stars stacked one above the other. The pump elements’ output volume is merged to feed one or more pressure outlets. The radial piston pump types R and RG have a closed pump housing. It can consequently be used both as an external motor pump not installed in an oil tank or as an integrated version installed inside a hydraulic power pack’s tank (see D 6010 H). The radial piston pump type RG has plain bearings which have an extended service life. Features and benefits: Very high efficiency Can be run with low-viscosity media Fine delivery flow rate gradation Long service life Operation not dependent on direction of rotation Intended applications: Industrial hydraulics Testing machinery Lubrication systems Hydraulic tools
Технические характеристики
CharacteristicsTyperadial pistonOther characteristicscompact, high-efficiency, oil, modular, two-stage, integratedPressure
700 bar (10,153 psi)
Flow rate
Min.: 6.5 l/min (1.72 us gal/min)
Max.: 91.2 l/min (24.09 us gal/min)
