Steel shear IC54 The steel shear iC45 has a weight of 5.450 kg, a mouth opening of 790 mm and a length of 3.700 mm. With hydraulic pressure adjusted to 350 bar its cutting capacity is enough to cut a 110 mm full round rod. TECHNICAL DATA SHEET WEIGHT kg5.450 MOUTH OPENING mm790 MOUTH DEPTH mm760 TOTAL LENGTH mm3.700 BUCKET POSITION ton46 — 65 BOOM POSITION ton29 — 45 WORKING PRESSURE bar350 WORKING FLOW l/m270 — 400 ROTATION PRESSURE bar110 ROTATION FLOW l/m30 CUTTING CAPACITY mm110 CUTTING CAPACITY (HEA) mm360 CUTTING CAPACITY (IPE) mm600
Технические характеристики
CharacteristicsHeating technologyhydraulicUsefor excavatorsProduct applicationsfor scrap metal, for steel, for ferrous metals
