Cross Flow Fan Blade Balancing Machines 1.Specially designed brackets transmit mechanical force with low vibration damping 2.Durable and reliable sensor possesses good linearity 3.Permanent calibration brings high accuracy with a permission of large initial unbalance amount 4.Belt-driving offers higher accuracy and easier operation 5.Advanced electrical measuring system and friendly man-machine interface 6.Cross flow fan balancer is applicable for all kinds of air-conditioner’s fan dryer tangential blower etc Technical data at a glance — PHG-5 Max Mass of Workpiece (kg) — 5 Max Diameter of Workpiece (mm) — 150 The distance between two bearing pedestals — Min 60-900 Length of workpiece(mm) — 900 Journal diameter on roller carriages — Φ5~12 Spindle speed(r/min) — 1470 stepless speed regulation Motor power(kw) — 0.2DC Min Achievable Residual Unbalance Amount (emar) — 0.5g· mm/kg
Технические характеристики
CharacteristicsOrientationhorizontalTypedynamicOperationmanualApplicationsfor fansOther characteristicshigh-accuracy, modular, compactRotational speed
1,470 rpm (9,236 rad.min-1)
Weight on rotor
Max.: 5 kg (11 lb)
Min.: 0.5 kg (1.1 lb)
