| Code | Description | Budget Price | Ship. weight | Ship. vol. | ||
|---|---|---|---|---|---|---|
| XCOLBOXC03E | COLD BOX, 3.6L VACCINE CARRIER, RCW4,ice packs 6×0.3L+1×0.6L | CH 323,72 | 0kg | 0 | Add | |
General information
Vaccine carrier for storage and transport of small quantities of vaccines.
Meets WHO/UNICEF Performance, Quality and Safety (PQS) Standard E004/VC002 (insulated containers/vaccine carrier — long range).
Supplied with 1 set of ice packs. A second set is required to ensure turnover.
Fitted with one polystyrene interior container and one synthetic separation wall to prevent direct contact between the vaccines and the frozen ice packs.
Two transparent pouches on the front allow to insert documentation for easy identification of the contents without having to open vaccine carrier.
Handle and adjustable shoulder strap included to enable easy transport.
The top part is equipped with grooves to facilitate the stable stacking of the boxes.
International agreement for air transport (ICAO-TI / IATA-DGR).
Includes instructions in English and French.
When ordering spare parts, please indicate the product number.
Replaces XCOLBOXC03T GioStyle, 3L, Vaccine Carrier
Specifications
Model | RCW4 |
Vaccine storage capacity | 3 litres |
Weight fully loaded | 7.3 kg |
Weight empty | 3.1 kg |
External surface material | Polyethylene |
Internal lining material | Polyethylene |
Insulation material | Polyurethane foam |
Insulation thickness | 25-27 mm |
Internal dimensions | 19x26x16 cm (HxWxD) |
Vaccine storage dimensions | 16x20x10 cm (HxWxD) |
Lid type & fixings | Hinged |
Number of icepacks required | 7 (1×0.6 litre + 6×0.3 litre) |
Number of icepacks supplied | 7 (1×0.6 litre + 6×0.3 litre) |
Icepack type | E5/09 (0.6 litre) and E5/08 (0.3 litre) |
Robustness in drop test | Fittings 3, Casing 4 |
Cold life, without opening (up to +10°C) | 30.3 hrs. at +43° |
Warm life (down to 0°C) | 12.9 hrs at -20°C |
External dimensions | 30 x 37 x 29 cm (HxWxD) |
Shipping weight/volume (1 piece) | 4.5 kg / 0.034 m³ |
Last update: 22/05/2019
