Химический анализатор Siemens Advia 2400

Product Description The ADVIA 2400 Clinical Chemistry System manages the most demanding workloads and meets high turnaround-time (TAT) goals. Its menu includes methods for testing drugs-of-abuse, therapeutic drugs (TDM) and new assays such as Cystatin C and CardioPhase hsCRP. The ADVIA 2400 Clinical Chemistry System offers: High throughput of up to 2,400 tests/hour (1,800 photometric and 600 ISE) to manage heavy workloads Rapid, consistent 2-second cycle time for faster tube speed and test throughput User-defined automatic repeat, dilution, and reflex testing Large onboard reagent capacity and optional concentrated reagents help to minimize intervention demands Refrigerated onboard storage of controls and reagents for extended stability and increased productivity Automation ready design no additional hardware required One Year Warranty Specifications Overview Type of System Random, continuous access, batch, discrete processing Throughput Rate Up to 2400 tests/hour: 1800 tests/hour colorimetric, 600 tests/hour ISE Assays Capacity Onboard 49 including 3 ISE Sample Handling Sample Tubes 5 mL, 7 mL, 10 mL, 2 mL sample cups Sample Tray 84 samples, positive sample identification Bar Codes Interleaved 2 of 5, code 39, code 128, Codabar (NW7) STAT Sample Loading 84, not dedicated Auto-repeat Automatic repeat testing from the retained pre-diluted sample Auto-dilution Automatic dilution from retained pre-diluted sample Auto-reflex Testing Automatic ability to perform 3 additional tests based on results of first test Primary Probe Liquid Level Sensing, Crash Protection, Clot/Clog Detection, Short Sample Detection Sample Integrity Check Qualitative check for hemolysis, lipemia and icterus Microvolume Technology Automatic Sample Predilution Samples diluted 1:5 (30 &mu,L sample + 120 &mu,L saline generates up to 15 test results), retained for auto-repeat until results are available Predilution Tray 120 dilution cuvettes Original Sample Volume 2 to 30 L, system uses an average of 2-3 L per test Average Reagent Volume 80-120 L per test Storage Capacity Onboard 20,000 tests average, Usage of concentrated reagents increases maximum capacity Reaction Area Reaction Tray 340 reusable plastic cuvettes Cuvette Optical Path Length 6 mm Reaction Bath Inert fluorocarbon oil circulation system, 37C Photometer 14 fixed wavelengths (340, 410, 451, 478, 505, 545, 571, 596, 658, 694, 751, 805, 845, and 884 nm) Light Source 12V, 50W halogen lamp, cooled by forced water circulation Assay Methods Endpoint, rate reaction, 2-point rate, multi-point homogeneous immunoassay Reaction Times 3, 4, 5, 10, 15 and 21 minutes Automatic Correction Serum blank, cell blank, measurement point change, sample volume change in reassay Point Forwarding Automatically extends linerarity over assay range samples Reagent Handling Reagent Tray 2 trays, 50 positions each, refrigerated Reagent Capacity Onboard 46 colorimetric methods Dispensing System 2 probes with Liquid Level Sensing and Liquid Surface Verification Reagent Wedges 20, 40 and 70 ml bar-code-labeled wedges Onboard Stability Up to 60 days Reagent Inventory Management Tracks tests remaining, lot number, onboard stability and expiration date Reagent Dilutions Capability to dilute concentrated reagents onboard Open System Capability Channels 200 channels, includes user-defined applications 3rd Party Applications Varies by country, can be configured on system ISE ISE Indirect simultaneous measurement of Na+, K+, Cl- Sample Volume 22L for all three tests Priming Automatic priming cycle Electrode Life 30,000 samples or 3 months Throughput Rate 600 tests/hour, 200 tubes/hour Calibration/QC Calibration Interval Up to 60 days, tracked by software Auto-Calibration/Auto-QC User-defined time interval or with new reagent wedge View Calibration/QC Data Graphical display of calibration curve and QC, Siemens Remote Service QC monitoring Calibration/Control Tray 61 refrigerated positions for calibrators, controls and diluents Data Management Computer Windows XP, flat panel display System Documentation Operator manual and assays sheets on-line Host Interface RS 232C bidirectional Data Storage 70,000 patient samples Onboard Maintenance Logs Schedule and monitor routine maintenance activities via software Host Query ASCII, system requests work order or batch of work orders from host General Specifications Power Requirements 100/115/200/220/230/240 V +/ 10%, 30 A, 50/60 Hz, 3 KVA Water Requirements Deionized water Maximum Water Consumption 40 liters per hour Drain requirements Minimum of 10.6 gallons (40) liters per hour. Dimensions ADVIA 2400: 52.8 (h) x 67.4 (w) x 34.1 (d) in, 134 (h) x 171.1 (w) x 86.7 (d) cm Weight ADVIA 2400: 1,389 lbs. (630 kg) Compliance cUL, CSA, CE Noise Specifications Open cover less than 70 db, closed cover less than 45 db Average Heat Output 5,374 BTU/hour Operating Temperature Range 18 30C/64 86F Ambient Humidity 40% 70%

Технические характеристики
