The N-LHR-121 Red HeNe Laser generates a randomly polarized output of 2.0 mW (minimum) at 633 nm. Longitudinal mode spacing is approximately 687 MHz with the spectral bandwidth being approximately 1400 MHz (FWHM). This CE compliant, IEC Class 3R red HeNe laser offers TEM00 mode at 633 nm. The power supply is included.
Технические характеристики
- Operating Wavelength 632.8 nm
- Polarization Random
- Output Power 2.0 mW
- Longitudinal Mode 687 MHz
- Beam Diameter (1/e2) 0.59 mm
- Beam Divergence Full Angle 1.35 mrad
- Beam Drift, Long Term
- CDRH Class IIIa
- Size 271.8 x Ø44.5 mm
- Noise
- Spatial Mode >90% TEM00
- Power Requirements 120/240 VAC 50/60 Hz
- Power Supply Size 128.3 x 60.9 x 133.4 mm
