With the machines of the DL E Heavy series, you can machine really large turning diameters and workpiece lengths. This lathe series is the solution for conventional machining of workpieces up to 8000 mm (315 in.) in length and over 1600 mm (63 in.) in diameter. The particularly wide and heavily ribbed machine bed takes heavy workpiece weights. Powerful motors drive the main spindle via a finely adjustable multi-disc clutch. The rapid traverse in the support is particularly effective with large bed lengths and the heavy tailstock is also moved with a motor drive. • Spindle bore of 130 mm • Powerful 22 kW motor • Sturdy multi-disk clutch • Rapid feed in X-and Z-direction • Complete with assembled 3-axis position indicator • 22 kW motor ensures high cutting power • Heavy-duty cast-iron body with ribbed bed reduces vibrations to a minimum • Induction hardened and ground guideways • Sturdy multi-disk clutch for headstock drive • Separate rapid feed motor for feed in X and Z direction • Joystick control for X and Z feeds is mounted directly to support • Motorized positioning of tailstock (all models with a minimum center width of 3000 mm) • Large spindle bearings • Includes completely assembled 3-axis position indicator • Overload clutch enclosed in apron
Технические характеристики
CharacteristicsControl typeCNCSpindle orientationhorizontalNumber of axes3-axisApplicationsheavy-duty, for large-diameter partsOther characteristicsuniversal, cuttingDiameter
1,000 mm, 1,250 mm, 1,600 mm, 2,000 mm (39.37 in)
Spindle speed
Min.: 3.15 rpm (19.792 rad.min-1)
Max.: 315 rpm (1,979.203 rad.min-1)
