JINPAT LPC-36T-1603-HD01-IP66(JP35-057-01HW) is a capsule slip ring model that takes up aluminum alloy as housing material. This model has 36 channels at total, among which 16 channels are 3A power channels and 1 HDMI channel. LPC-36T-1603-HD01-IP66 adopts gold to gold contact which contribute to its great electronic performance and smooth operation during rotations. The rotating speed ranges from 0~400rmp. This slip ring model can work in low and high temperature while maintain a fine and stable operation. It can also cope with humid environment, withstands humidity below 60%RH. With protection grade up to IP66, JINPAT LPC-36T-1603-HD01-IP66 is able to transmit signal and power in a stable and reliable way even in a demanding environment. Electrical & Electronics — Mechanical Number of Circuits — 36CKT — Rotating Speed — 0-400rpm 16Circuits*3A /1Circuit*HDMI Rating Voitage — 0~70V AC/DC — Contact Material — Gold-to-gold Insulation Resistance — ≥100MΩ@500VDC(P)≥10MΩ@100VDC(S) — Housing Material — Aluminum Alloy Dielectric Strength — ≥500VAC@50Hz(P)≥100VAC@50Hz(S) — Lead Wire Length — Stator:250±5mm Rotor:250±5mm Environment — Remarks Working TEmperature — -20℃~+60℃ — Application — / Working Humidity — ≤60％RH — Other — / IP — 66 — Note:’P’stands for power,’S’stands for signal.
Технические характеристики
CharacteristicsTypeHD-SDI, HDMIConstructioncapsuleApplicationsfor robotics, for radar antennas, for CCTV applications, for industrial applications, for offshore applicationsMaterialaluminum alloyOther characteristicswith gold contactsVoltage
70 V
Primary current
3 A
Rotational speed
400 rpm (2,513 rad.min-1)
Number of channels
16 unit
