halogen-free flexible paired data cable with aluminum pair screen and overall copper screen Marking for SABIX BL 446 C FRNC FTP 64462475: SAB BRÖCKSKES · D-VIERSEN · SABIX® BL 446 C FRNC FTP 24x(2×0,75mm²)ST — IEC 60332-3-22 — 300V DNV CE and current meter marking Halogen-free flexible paired data cable with aluminum pair screen and overall copper screen especially for use in shipbuilding industry. The flexible & flame retardant cable is suitable for applications acc. to Hong Kong Convention. halogen-free asbestos-free screened, good EMC characteristics good transmission rates and crosstalk attenuation no flame propagation flame retardant and self-extinguishing flexible for applications acc. to Hong Kong Convention ingredients tested acc. to the requirements of the Hong Kong Convention (2009) of the IMO approvals: DNV Possible on request bare copper strands alternative colour code and sheath colour Conductor — tinned copper strands acc. to IEC 60228, VDE 0295, class 5 Insulation — special SABIX® Colour code — ≤ 0,25 mm2 = DIN 47100 ≥ 0,34 mm2 = white, blue with marking, pairnumber Stranding — cores white, blue twisted to pairs Pairscreen — alu foi Stranding — pairs together in layers Wrapping — PETP-foil Screen — tinned copper braiding Wrapping — PETP-foil Sheath material — special SABIX® SHF 1 compound acc. to IEC 60092-360 Sheath colour: — pigeon blue (RAL 5014)
Технические характеристики
CharacteristicsTypedataFormatDINProtectioninsulated, flame-retardant, with copper screen, self-extinguishingConfigurationpairedCore materialcopper, aluminumApplicationsindustrial, for marine applicationsColor of the insolationwhite, blueNormsIECOther characteristicsflexible, halogen-free, asbestos-freeNominal voltage
300 V, 1,200 V, 1,500 V
Temperature
Min.: -40 °C (-40 °F)
Max.: 90 °C (194 °F)
Cross-section
0.25 mm², 0.34 mm², 0.75 mm², 1.5 mm² (0 in²)
