Dimension 24 x 3 x 3.75 mm Principle of operation Magnetic field sensor Connection M8x1-Male, 3-pin Cable PUR, 0.3 m Application Pneumatic cylinder with C-slot, e.g. SMC, Festo*, Schunk, Sommer, Gimatic (*not suitable for Festo Series ADVC and AEVC) Fastening detail can be installed in C-slot from above Housing material PA 12 Switching output PNP normally open (NO) Switching frequency 3000 Hz Operating voltage Ub 10…30 VDC Ambient temperature -25…85 °C IP rating per IEC 60529 IP67 Approval/Conformity cULus CE UKCA WEEE
Технические характеристики
CharacteristicsTechnologyHall effect
