H50JA Series Hall Effect Joystick — Hall effect joystick — 1-dimensional coordinate type, 2-dimensional coordinate type, 3-dimensional coordinate type — Suitable for strong vibration Standard Mechanical Specifications — Operating angle: Approx. ±18°~ ±22°(2-dimensional type,Omni-directional) — Operating force: Approx.0.5~0.8N (X/Y, with spring return device) — Mechanical life expectancy: Approx.10,000,000 operations — Operating temperature range: -20℃~+65℃ — Vibration: 10~55Hz 98m/S2 — Shock: 294m/S2 Standard Electrical specifications (Hall effect potentiometer) — Input voltage: 5V — Output signal: 0.5V~4.5V — Electrical roating angle:Approx.18°(X/Y) — Independent linearity tolerance: ±3% — Load resistance: — >10KΩ — — — Dielectric strenghth: 1 minute at 250V.A.C — Insulation resistance: >100MΩ at 250V.D.C H50JA can be customized in accordance with your special requirements. Please contact us at trade1@sakae.cn for customization.
Технические характеристики
CharacteristicsTechnologyHall effect, analog, single-axis, 2-axis, potentiometer, switch, 3-axis, compact, micro-switch, contactless inductiveApplicationsfor remote control, for utility vehicles, for off-highway vehicle, for aerial work platform, for motorized stages, for marine applicationsOther characteristicswith buttons, rugged, multifunction, panel-mount, with switch
