H40JH Series Hall Effect Joystick — Hall effect joystick — Low-cost High protection 3-dimensional coordinate type — Single output, dual cross output, dual parallel output — With dust proof rubber cover — With spring return device Standard Mechanical Specifications — Operating angle: Approx.±20°(X/Y), ±30°(Z) — Operating force: Approx.1~4N (X/Y), 40~80Nm.m(Z) — Mechanical life expectancy: Approx.5,000,000 operations(X/Y), Approx.3,000,000 operations(Z) — Operating temperature range: -20℃~+60℃ — Vibration: 10~55Hz 98m/S2 — Shock: 294m/S2 Standard Electrical specifications (Hall effect potentiometer) — Input voltage: 5V — Output signal: 0.5V~4.5V — Electrical roating angle:Approx.20°(X/Y), Approx. 30°(Z) — Independent linearity tolerance: ±3% — Load resistance: — >10KΩ — — — Dielectric strenghth: 1 minute at 500V.A.C — Insulation resistance: >1000MΩ at 500V.D.C H40JH can be customized in accordance with your special requirements. Please contact us at trade1@sakae.cn for customization.
Технические характеристики
CharacteristicsTechnologyHall effect, analog, potentiometer, switch, 3-axis, compact, contactless inductiveApplicationsfor remote control, for medical applications, for utility vehicles, for CCTV applications, for off-highway vehicle, for aerial work platform, for motorized stages, for marine applications, for assistive technologyOther characteristicswith buttons, rugged, IP65, multifunction, with switch
