Ergo Glass® Pneu. Rotation & Tilt The Ergo-Glass end effector that, when integrated in Quick-Lift System®, meets the highest standards of ergonomics, working environment, safety and efficiency. Equipped with fixed one or two (round) suction cups. The control handle provides a logic and simple interface for the operator for up and down movement as well push buttons for grip and release of the glass panels. The control box at the top provides setting of adjustable speed depending of the application. The control box at the top provides setting of adjustable speed depending of the application. Pneumatic rotation and tilt glass panels. Main direction of suction cups is to be defined. 1 Rotative head mounted on free bearing End effector with driven rotation. Vertical portrait towards flat laying.
Технические характеристики
CharacteristicsProduct applicationsglass plateTypehorizontal, verticalPowerpneumaticOptionsrotaryCarrying capacity
65 kg, 115 kg, 150 kg (143 lb)
Weight
34 kg (74.96 lb)
