Single Mode Fiber Optical Joint With Gigabit Ethernet Signal Can Working In Very Low Temperature ECN000-09P-22S-01EG-01F, one of CENO fiber optical joint, customized for photoelectric pod industry.The joint is integrated with 9 channels of currents,two circuits of 40A current, 1 channel single-mode fiber, 22 channels signals and a set of gigabit Ethernet signals.The structure is compact.Its out dimension is 62mm and body length is 119mm. This joint can be adaptable, working environment from — 40 ℃ to + 80 ℃ to meet the requirement of electro-optical pod system performance. Features Integrate Fiber optic rotary joint and power slip ring Transmit fiber optic signal ,no disclose,no EMI Reliable performance
Технические характеристики
CharacteristicsTypegigabit EthernetApplicationsfor rotary tables, for radar antennas, for marine applications, medicalOther characteristicswith gold contacts, IP54, FC type, SMA, with fiber optic rotary jointVoltage
380 V
Primary current
Max.: 40 A
Min.: 2 A
Rotational speed
Max.: 300 rpm (1,885 rad.min-1)
Min.: 0 rpm (0 rad.min-1)
Number of channels
33 unit
