Features:
- Highest power density 2400W available in 1U size.
- Output voltage up to 600V, Output current up to 400A.
- Built in RS323/RS485 Interface (optional GPIB)
- Miniaturization with heat dissipation design.
- Front panel will intake the air and release it through the back panel makes stacking is possible.
- Built-in 16 bit high resolution A/D D/A converter.
- Parallel operation with active current sharing.
- Last Setting Memory.
- The last setting will be saved after the power is OFF. It is unnecessary to set up again when powered back on.
- F. There is unessecary to do resetting again during swicth on.
Specifications:
- 750 W
- 6 V
- 100 A
The GEN6-100 is a 750 W, 6 V, 100 A dc power supply from Lambda.
Технические характеристики
| Manufacturer | Lambda |
|---|---|
| Condition | Used |
| Current | 100 A |
| Voltage | 6 V |
| Power | 750 W |
