Our R10 is a full plastic gearhead designed in a one piece construction for better gear train alignment. Due to this feature and also due to fact that a unique geartube material is used leads to lower noise and longer life. The R10’s lower backlash feature makes it ideally suited for precision motion requirements in various applications. Product Highlights — For additional ratios, please download the specification pdf from the resources tab below — High-precision performance at a competitive price point — Reduction ratio of 4:1 to 4096:1 — Better power to weight ratio — Sleeve and ball bearings options available — Compact design — Rated torque 0.1 Nm — Customization as per application needs Customization Available — Custom shafts — flats, knurling, diameter, length — Mechnical integration upon request (housing, front & rear flange, shaft) — Ratios — Special lubricants
Технические характеристики
CharacteristicsTypegear trainShaft orientationcoaxialTorque0 — 0.1 NmShaft configurationsolid-shaftNumber of stagessingle-stage, multi-stagePerformancelow-backlash, low-noise, high-precision, high-speedOther characteristicscompact, miniature, with plastic frameRotational speed
10,000 rpm (62,831.85 rad.min-1)
Backlash
1 °, 3 °
