Made for the gear-cutting sector Clamping solutions for the gear-cutting sector are individual and have very special requirements. Consequently, it is not easy to find the suitable clamping device, particularly in the case of high variant diversity and smaller lot sizes. The conventional solution is to use fixtures that are more or less effective. Rigid and narrow standard segmented mandrel Fortunately, this is now history. With the MANDO G211 you are relying on a standard segmented mandrel. You profit from in-stock segmented clamping bushings. The rigid and narrow mandrel with optimized tool runout contour is ideal for use in gear cutting applications. Moreover, it can also be used for gear shaping or grinding. Three end-stop levels that are placed with different proximity to the workpiece make it possible to use individual workpiece end-stops. Also a coolant connection ensures process reliability.
Технические характеристики
CharacteristicsApplicationfor gear cuttingOther characteristicsquick-change, radialClamping range
Max.: 120 mm (4.72 in)
Min.: 20 mm (0.79 in)
Rotational speed
Max.: 600 rpm (3,770 rad.min-1)
Min.: 0 rpm (0 rad.min-1)
