— Pre-filter with mounting flange adapter for gas sampling from processes with high dust levels — Mounting flange adapter made of stainless steel with 4 welded-in threaded bolts — Double-layer structure for high back-purging efficiency — For dust loads > 10 g/m3 — Mounting flange size: DN 65 PN 6 B — Length: 500 mm [≈ 1.6 ft] — Filter porosity: 1 µm — Sampling temperature: max. +1000 °C [+1832 °F] — Material of sample-contacting parts: ceramic, stainless steel, Novapress® Ceramic pre-filter, up to max. 1000 °C, in different versions The M&C pre-filters are used in combination with the M&C gas sample probe series SP for continuous gas sampling in processes with an increased level of dust. Pre‑filter type V12‑1 for SP2000‑H, large in‑situ ceramic filter tube as a double‑layer version for high blowback efficiency, without internal volume displacer, length: 500 mm, 40 mm o.d., filter porosity: 1 µm, temperature: max. 1000 °C, mounting flange DN 65 PN 6B with 4 welded mounting screws, incl. gasket, material: ceramic, SS 316Ti
Технические характеристики
CharacteristicsSample typegasTechnologyprobe
