— Pre-filter for gas sampling from processes with high dust levels — For cleaning purposes: pre-filter can be back-purged — For dust loads from 2 to 10 g/m3 — Male thread connection: G 3/4′ — Length: 220 mm [≈ 0.7 ft] without thread connection — Filter porosity: 2 µm — Sampling temperature: max. +600 °C [+1112 °F] — Material of sample-contacting parts: stainless steel, Novapress® Stainless steel pre-filter, up to max. 600 °C, in different versions The M&C pre-filters are used in combination with the M&C gas sample probes series SP for continuous gas sampling in processes with an increased level of dust. Pre‑filter type V20 for SP2000‑H, stainless steel pre‑filter without volume displacer, length: 220 mm, 46 mm OD, filter porosity: 2 µm, temperature: max. 600 °C, connection: G 3/4′, material: SS 316L/316Ti
Технические характеристики
CharacteristicsSample typegasTechnologyprobeOther characteristicsstainless steel
